Dual heat burners in Addition to double Room burner Burning ability up to 30 Kg per hour with wet scrubber

Model

YD-30C

Feed Ability

Ordinary 50 kgs per feeding

Burning Price

Typical 30 kgs per hour

Burning Time per Feed

2 hours

Voltage

380V

Power

6 Kw

Fuel

Natural Gas

Heater

Italy Heater

Feed Setting

Handbook

Gas usage (Oil)

10.2-20.0 Kgs/Hour

Gas usage (Gas)

12.2-24.0 m3/Hour

Outside Measurements

170 x 140 x 190cm (text)

Interior Measurements

55 x 55 x 85cm( Main Chamber)

Waste combustion chamber

250Liters

Article Combustion Chamber

140Liters

Oil Tank Capacity

100 Litres

Door Opening

38 x 48cm

Chimney

5.0 M

Gross Weight

3300kgs

Chamber Material

Refractory Concrete

Max.

200,000 Kcal/Hr.

Operation Technical Specs

Solid Chamber temperature

8000C -10000 C

Concentration camp temperature level

10000C -12000 C

Chamber Anti-Rate

13500C

Residency time

2.0 Sec.

Burning efficiency

＞ 98 percent

Waste Lower Calorific Power
